| CAPACITY | 100T |
| VARIABLE STROKE | 20-140 mm |
| STROKING RATE STROKE / STROKE | 50 / 80 s.p.m |
| CONTINUOUS STROKING RATE | 45 s.p.m |
| DEPTH OF THROAT | 355 mm |
| SHUT HEIGHT | 340 mm |
| RAM ADJUSTMENT | 80 mm |
| TABLE AREA | 900 x 710 mm |
| RAM AREA | 560 x 450 mm |
| TABLE HEIGHT ABOVE GROUND | 800 mm |
| MOTOR | 11,5 KW |
| DIMENSIONS: | |
| WIDTH: | 1650 mm |
| DEPTH: | 2250 mm |
| HEIGHT: | 3050 mm |
| WEIGHT OF PRESS | 9,1T |
