| TYPE | PHG100 |
| NOMINAL CAPACITY | 100T |
| MAX. STROKE | 220 mm |
| SCREW Ø | 100 mm |
| STROKING RATE | 52-68 s.p.m |
| TABLE | 400x450 mm |
| HOLE IN TABLE | Ø 60 mm |
| RAM | 378x320 mm |
| DISTANCE BETWEEN UPRIGHTS | 490 mm |
| DISTANCE BETWEEN SLIDES | 380 mm |
| DISTANCE TABLE / RAM MINIMUM | 225 mm |
| TABLE HEIGHT ABOVE GROUND | 600 mm |
| MOTOR | 10 HP |
| DIMENSIONS | |
| WIDTH | 1530 mm |
| DEPTH | 1500 mm |
| HEIGHT | 3067 mm |
| APPROX WEIGHT | 3,8T |
