| ENERGY OF BLOW | 3600 kg.m |
| WEIGHT OF FALLING RAM | 1250 Kg |
| MAX. TUP STROKE | 800 mm |
| GUIDEWAY SPACING | 550 mm |
| LENGTH OF DIE SEAT IN THE TUP | 500 mm |
| LENGTH OF DIE SEAT IN THE CUSHION | 700 mm |
| MIN. HEIGH OF THE DIE (without dovetail | 220 mm |
| MAX. WEIGHT OF UPPER DIE | 400 Kg |
| STROKING RATE | 110 s.p.m. |
| STEAM OR INCOMING AIR PRESSURE | 5-7 Kg/cm2 |
| AVERAGE STEAM CONSUMPTION | 650 Kg/h |
| AVERAGE AIR CONSUMPTION | 12 m3/mm |
| HEIGH ABOVE THE FLOOR | 3750 mm |
| TOTAL HEIGHT | 4380 mm |
| WEIGHT OF ANVIL | 24T |
| TOTAL WEIGHT OF THE HAMMER | 35T |
