| CAPACITY | 400T |
| SERIAL N° | 4174847 |
| VARIABLE STROKE | 25-250 mm |
| SHUT HIGH | 510 mm |
| RAM ADJUSTMENT | 150 mm |
| STROKING RATE | 25-50 s.p.m |
| TABLE (left to right x front to back) | 1650x1000 mm |
| HOLE IN TABLE | 820x670 mm |
| TABLE THICKNESS | 170 mm |
| RAM (left to right x front to back) | 1350x900 mm |
| MOVABLE TABLE THICKNESS | 170 mm |
| DEPTH OF THROAT | 510 mm |
| DISTANCE BETWEEN UPRIGHTS | 1370 mm |
| MOTOR | 30 KW |
| EJECTION STROKE | 80 mm |
| PRESS HEIGHT | 4750 mm |
| PRESS WEIGHT | 42T |
