| ENERGY OF BLOW | 40 000 Kg/m |
| RAM STROKE | 1450 mm |
| MAX. STROKING RATE | 80 s.p.m |
| AVERAGE STROKING RATE | 6 s.p.m |
| UPPER RAM WEIGHT | 43T |
| LOWER RAM WEIGHT | 47T |
| AIR CONSUMPTION (hardest stroke) : | |
| - Cold air | 5,3 m3 |
| - Hot air 220°C | 3,2 m3 |
| AIR CONSUMPTION : | |
| - Cold air (at average stroking rate) | 32 m3/mn |
| - Hot air 220°C (at average stroking rate) | 19 m3/mn |
| USABLE COMPRESSOR POWER : | |
| - Cold air (at average stroking rate) | 240 HP |
| - Hot air 220°C (at average stroking rate) | 140 HP |
| DISTANCE BETWEEN SLIDES | 1200 mm |
| MIN. DIES HEIGHT (witout dovetail) | 575 mm |
| HEIGHT ABOVE THE FLOOR | 6200 mm |
| TOTAL WEIGHT | 235T |
